| Mega Pixel | 1.0MP 960P |
| Video Compression | H.264 |
| Shutter Time | 1/100s -1/120s |
| Operating System | Embedded Linux |
| Lens | fix lens:3.6mm,4mm,6mm,8mm,12mm optional; (With IR-CUT Built-in) |
| Video Stream | Main stream:1280*960; Sub stream:720*576 |
| Video bite rate | 128Kbps-5096Kbps continuously-adjustable |
| Frame Rates | 25fps |
| audio | G.711 A-Law @ 16bits 8kbps |
| Min. Illumination | Color: 0.5 Lux |
| B/W: 0.01 Lux | |
| Protocols/Network function | Tcp/UDP/rtp/rtsp/rtmp/http/DDNS/P2P/ONVIF 2.4 |
| White Balance | Auto |
| Day & Night | Auto / Color / BW |
| 3D-DNR | Auto |
| Auto Focus | Not Support |
| DRC | Auto |
| SD card | Support |
| Mirror/Flip | On / Off |
| Privacy Masking | 4 Zone Selectable |
| OSD | Date Time & Title |
| Network interface | RJ45 10M/100M adaptive Ethernet interface |
| Users | 4 |
| Onvif | Support Onvif 2.4 |
| IR LED | 3 Array LED ; IR CUT filter with auto switch |
| IR LED distance | 30-40 metres |
| POE | Support(built-in) |
| Special Feature | Support remote view by Mobilephone(Esee
application for android, eseenet for iphone) |
| Free DDNS | www.e-seenet.com/www.dvrskype.com |
| Web Browser | IE, chrome, safari, firefox |
| Material | Metal |
| Color | White |
| Working Environment | -10 °C-60°C , 10%-90% RH |
| Water Proof | IP66 |
| Thunder Prevention | Standard IEC61000-4-5 |
| Power supply | DC12V 1A /POE module optional |
| Power consumption | ≤6W |
